How to tell if an optical cable is a composite optical cable

Fiber and communications infrastructure knowledge brief Published 14 Apr 2024

Prepared for preliminary research by the METRA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Composite optical cables typically contain single-mode or multimode glass fiber cores for high-speed data transmission, integrated alongside copper conductors for power or additional data.

Structure of Composite Optical Cables

A composite optical cable combines optical fibers and electrical conductors within a single jacket, allowing simultaneous transmission of data and power. The optical portion of the cable consists of fiber optic cores, which are usually made of high-purity glass (silicon dioxide, SiO₂), though some fibers may be plastic for short-distance applications. These fibers are coated with protective layers to prevent damage and maintain signal integrity.

Types of Optical Fibers UsedSingle-Mode Fiber (SMF): Core diameter: typically 8–10 micronsTransmits light at a single wavelength, ideal for long-distance, high-bandwidth applicationsCommonly used in telecommunications and data centers Multimode Fiber (MMF): Core diameter: typically 50–62. 5 micronsSupports multiple light paths, suitable for shorter distances like within buildings or campusesOften used in AV systems and local networks Composite cables may include two or more single-mode fibers or a combination of single-mode and multimode fibers, depending on the application. The fibers are pre-terminated with connectors (e.g., LC, SC) and labeled for easy identification.

Integration with Copper ConductorsThe copper conductors in a composite cable provide electrical power or additional data channels, enabling devices like surveillance cameras, traffic signals, or remote communication equipment to receive both power and high-speed data through a single cable. This design improves space efficiency, installation speed, and durability compared to running separate fiber and power cables.

Applications

Composite optical cables are widely used in: Surveillance systemsData centersIndustrial automationSmart city infrastructureUrban and rural communication networks The optical fibers inside these cables ensure high-bandwidth, low-latency, and interference-resistant data transmission, while the copper conductors provide reliable power delivery.
