Price of right-angle elbow for cable trays

The price of a right-angle cable tray elbow varies widely depending on material, size, and manufacturer, typically ranging from $10 to $100 or more per piece.

Overview

A right-angle elbow is a common cable tray fitting used to change the direction of cable runs by 90 degrees. These fittings are essential for routing cables around corners or obstacles in industrial, commercial, or data center installations. They are available in various materials, including galvanized steel, stainless steel, aluminum, and fiberglass-reinforced plastic (FRP), which affects both durability and cost.

Factors Affecting Price

Material: Stainless steel and FRP elbows are generally more expensive than galvanized steel or aluminum due to corrosion resistance and strength. Size and Width: Larger cable trays require larger elbows, which increases material usage and cost. Duty Rating: Heavy-duty elbows designed for industrial applications cost more than light-duty versions used in office or low-load environments.

Supplier and Customization: Some manufacturers offer custom-fabricated elbows to match specific tray systems, which can increase the price.

Typical Price Range

Small to medium-sized galvanized steel elbows: $10–$30 per pieceStainless steel or heavy-duty elbows: $40–$100+ per pieceCustom or specialized elbows: Prices vary and may require a quote from the supplier Where to PurchaseSuppliers such as RS Components, JLH Electric, and other cable tray manufacturers provide a range of elbows and fittings. Many offer online catalogs where you can select the material, size, and type, and request a quote for exact pricing. For accurate pricing, it is recommended to contact the supplier directly with your tray specifications, material preference, and quantity requirements.

This ensures compatibility and provides the most up-to-date cost.
