What does SCFC pigtail fiber mean

Fiber and communications infrastructure knowledge brief Published 26 Mar 2023

Prepared for preliminary research by the METRA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

SC-FC fiber optic pigtails are short fiber cables with SC and FC connectors pre-terminated on one end, designed for splicing to backbone fibers to ensure low-loss, reliable connections.

Overview

A fiber optic pigtail is a short length of fiber cable with a factory-installed connector on one end and an exposed fiber on the other, intended for fusion or mechanical splicing to a main fiber line. SC-FC pigtails combine SC (Subscriber Connector) and FC (Ferrule Connector) types, allowing flexible connectivity between equipment with different interfaces.

The S

C connector is known for its durable snap-in design, widely used in telecom and data networks, while the FC connector features a screw-on mechanism, providing a secure connection suitable for high-vibration environments.

Types and Specifications

Fiber Mode: Available in single-mode (OS2, 9/125µm) for long-distance, high-bandwidth applications, and multimode (OM1/OM2/OM3/OM4) for shorter distances within buildings or campuses. Polish Types: UPC (Ultra Physical Contact): Standard polish with low back reflection, typically blue connectors.

AP

C (Angled Physical Contact): 8-degree angled polish for superior return loss, typically green connectors, ideal for RF video or high-precision applications. Cable Structure: Tight-buffered for protection, with partial outer jackets to allow flexibility and accommodate tight bend radii. ApplicationsSC-FC pigtails are commonly used in: Data centers and LANs for connecting patch panels and transceivers.

Telecom and CAT

V networks for backbone termination.

FTT

H (Fiber to the Home) and PON networks. Testing and high-vibration environments where FC connectors provide stability. AdvantagesFactory-terminated connectors ensure low insertion loss and high return loss, improving network performance.

Bend-insensitive fibers reduce attenuation when twisted or bent, simplifying installation and maintenance. Compatibility with multiple connector types allows flexible integration into existing networks. Time-saving: Pre-terminated ends reduce field termination errors and installation time.

Installation

The unterminated end of the pigtail is spliced to the main fiber using fusion or mechanical splicing, creating a stable and reliable connection point. SC-FC pigtails can be used in high-density enclosures, with the outer jacket stripped as needed to accommodate tight bends. SC-FC fiber optic pigtails are essential for ensuring high-performance, low-loss connections in modern fiber optic networks, providing both flexibility and reliability for diverse applications.
