Fiber optic patch cord lc to lc

An LC to LC fiber optic patch cord is a high-performance cable with LC connectors on both ends, used for reliable, high-speed optical transmission in data centers, telecom, and enterprise networks.

Overview

An L

C to LC fiber patch cord features LC connectors on both ends, which are compact, push-pull latch connectors with a 1. 25mm ferrule diameter, ideal for high-density network environments. These cables are available in single-mode (SMF) for long-distance transmission and multimode (MMF) for high-bandwidth, short-distance links.

They are commonly used in data centers, telecom backbones, enterprise networks, and inter-building connections.

Key Features

Connector Type: LC to LC, with secure push-pull latch for precise alignment. Fiber Type: Single-mode (OS2, SMF28®) or multimode (OM1, OM2, OM3, OM4, OM5) depending on distance and bandwidth requirements. Duplex or Simplex: Duplex cables support simultaneous bidirectional communication, while simplex is single-direction.

Insertion Loss: High-quality LC connectors typically provide low insertion loss (~0. 15 dB) and excellent return loss for reliable performance. Jacket Options: Indoor, plenum (OFNP), riser (OFNR), or armored for outdoor use.

Length: Customizable from 0. 3 meters up to 300 meters. Polish Types: UPC (Ultra Physical Contact) or APC (Angled Physical Contact) for different reflection and signal requirements.

Applications

Data Centers: High-density patch panels and rack installations. Telecom Networks: Backbone and metro fiber connections. Enterprise Networks: Interconnecting switches, routers, and servers.

Inter-

Building Links: Long-distance single-mode connections between buildings.

Advantages

Compact Size: LC connectors allow more ports per panel, maximizing rack efficiency. High Performance: Minimal signal loss and high reliability for mission-critical applications. Versatility: Supports both short-range multimode and long-range single-mode applications.

Customizable: Available in various lengths, jacket types, and polarity configurations to match network requirements.

LC to L

C fiber patch cords are essential for modern high-speed networks, providing efficient, reliable, and space-saving connectivity for both short and long-distance optical communication.
