H3C optical module interface model

Fiber and communications infrastructure knowledge brief Published 24 Sep 2023

Prepared for preliminary research by the METRA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

H3C optical modules include SFP, SFP+, XFP, QSFP, QSFP28, QSFP56, DAC, and AOC transceivers supporting data rates from 100 Mbps to 400 Gbps.

Overview of H3

C Optical ModulesH3C optical modules are designed for optical-to-electrical and electrical-to-optical conversions and support functions such as optical power control, modulation transmission, signal probing, IV conversion, and decision regeneration. They are available in multiple form factors including SFP, SFP+, SFP28, QSFP, QSFP28, QSFP56, CFP, CFP2, and CXP. Modules are categorized by data rate, transmission distance, and central wavelength (850 nm, 1310 nm, 1550 nm) to meet different networking requirements ( ).

Common H3

C Optical Module TypesSFP (Small Form-factor Pluggable): 100 Mbps to 1 Gbps, short- and long-range options. SFP+: 10 Gbps, commonly used for enterprise and data center networks. SFP28: 25 Gbps, suitable for high-speed server connections.

QSF

P: 40 Gbps, widely used in backbone networks. QSFP28: 100 Gbps, supports high-density data center applications. QSFP56: 200 Gbps, designed for next-generation high-speed networks.

CFP/CFP2: 100 Gbps and above, for long-haul and metro networks.

CX

P: 100 Gbps, used in high-performance computing and data centers.

DA

C (Direct Attach Copper) & AOC (Active Optical Cable): Short-range interconnects for servers and switches ( ). Data Rates and Transmission DistancesH3C optical modules support a wide range of data rates: 100 Mbps, 155 Mbps, 622 Mbps, 1 Gbps, 2 Gbps, 2. 5 Gbps, 4 Gbps, 8 Gbps, 10 Gbps, 16 Gbps, 25 Gbps, 32 Gbps, 40 Gbps, 50 Gbps, 100 Gbps, 200 Gbps, and 400 Gbps ( ).

Transmission distances are classified as: Short-range (SR): ≤ 2 kmLong-range (LR): up to 10 km or more, depending on fiber type and module specifications ( ).

Example H3

C Optical Module Models10

G Modules: 10G-SR, 10G-LR, 10G-LRM25G Modules: 25G-SR, 25G-LR40G Modules: 40G-QSFP+, 40G-LR4100G Modules: 100G-QSFP28-SR4, 100G-QSFP28-LR4200G Modules: 200G-QSFP56-SR4, 200G-QSFP56-LR4400G Modules: 400G-QSFP-DD, 400G-QSFP-DD-LR4 ( ).

Selection Considerations

When choosing H3C optical modules, consider: Device compatibility: Ensure the module is supported by the H3C switch or router. Data rate requirements: Match the module speed to network needs. Transmission distance: Select SR or LR based on fiber length.

Wavelength: Choose 850 nm for short-range, 1310 nm or 1550 nm for long-range applications ( ).

H3

C provides a wide range of optical modules to support enterprise, data center, and carrier-grade networks, ensuring flexibility for different network topologies and performance requirements.
