How to raise the cable tray height

Cable tray height can be adjusted using vertical hangers, threaded rods, and specialized adjustable couplers to ensure proper alignment and support between tray sections.

Vertical Hanger and Threaded Rod Method

One common technique involves using threaded rods with hex nuts and washers to adjust the height of cable trays. The process typically includes: Installing vertical hangers or threaded rods at the desired tray locations. Placing square or round washers and cross members on the rods.

Threading hex nuts above and below the cross member to allow fine vertical adjustment. Lifting the tray section so the threaded rod passes through the clamp or tray clip, then tightening the nuts to secure the tray at the desired height. This method allows precise vertical positioning and minor horizontal adjustments depending on rod length, ensuring trays are level and properly supported.

Adjustable Couplers

For connecting adjacent tray sections at different heights, vertical adjustable couplers are widely used: These couplers feature easi-bend slots that allow on-site adjustment for vertical and horizontal offsets. They can connect trays directly to walls, floors, or other tray runs, forming tee connections or offsets. Couplers are supplied with fixings and are compatible with the full range of tray side wall heights, providing flexibility for complex installations.

Trapeze or Swing Support Systems

Another method involves trapeze or swing supports, where the tray is suspended from a horizontal cross member: The cross member is attached to vertical hangers, allowing the tray to be raised or lowered by adjusting the nuts on the hangers. This system is particularly useful for long runs or when multiple trays need to be aligned at the same height.

Best Practices

Ensure all vertical hangers and couplers are properly sized for the tray load and comply with relevant standards (e.g., BS EN 61537). Allow sufficient clearance for tray clips and horizontal adjustment when installing cross members. Verify that trays are level and secure before routing cables.

Avoid using trays as lifting points; always use the designed supports and couplers for height adjustment. By combining threaded rod adjustments, trapeze supports, and vertical adjustable couplers, installers can achieve precise alignment, accommodate height differences, and maintain safe, stable cable tray systems.
